APPLICATIONS:

These capacitors are designed to use in glow startes of fluorescent lamps for sparking suppression.

TECHNICAL DATA:

- Climatic category:                                 - 55/085/21
- Electric strength of insulation at ac. Voltage 50Hz, 60s:
        between terminals                            - 1500 Vac
        between terminals and case           - 2000 Vac
- Dissipation factor :                                 - 0,01 at f=1000Hz
- Insulation resistance Riz at +200C :     - 7500 MOhms
- Switching ability at 1250VAC:              - 50 000 cycles
- Specifications: ZN-91/MP/MIFLEX/05
